Frame: Galvanized Steel Sheet / Aluminum Alloy Sheet

Filter Media: Superfine Glass Fiber Filter Paper

Separator: Hot Melt Adhesive

Sealant: Polyurethane

Filtration Efficiency: H11 (EN1822): 95%@MPPS (≥99%@0.3μm)

      H13 (EN1822): 99.95%@MPPS (≥99.99%@0.3μm)

      H14 (EN1822): 99.995%@MPPS (≥99.999%@0.3μm)

Each unit is inspected by laser particle scanning test before delivery

Continuous Operating Temperature: ≤70℃

Humidity Resistance: ≤100%RH

Recommended Max. Final Resistance: 600Pa

Application: Main filter for clean rooms, commercial and industrial HVAC systems; applicable to high humidity air conditioning systems, variable air volume systems, installation-space-limited ventilation systems, and ventilation systems with high fireproof requirements or relatively high airflow temperature.

Notes: ① Filter pleats and separators shall be placed vertically during use; ② Please read and strictly follow installation instructions before installation and operation.
