Frame: Aluminum Alloy

Filter Media: Ultra-fine Glass Fiber Filter Paper

Separator: Hot Melt Adhesive

Sealant: Polyurethane

Protective Mesh: Powder-coated steel mesh in white, equipped on both air inlet and outlet sides.

Filtration Efficiency (EN1822):

H10: ≥85% @ MPPS (≥90% @ 0.3μm)

H11: ≥90% @ MPPS (≥95% @ 0.3μm)

H12: ≥95% @ MPPS (≥99% @ 0.3μm)

H13: ≥99.5% @ MPPS (≥99.99% @ 0.3μm)

H14: ≥99.995% @ MPPS (≥99.999% @ 0.3μm)

Max Continuous Operating Temperature: ≤70℃

Humidity Resistance: ≤100%RHMPPS = Most Penetrating Particle Size

Application: Terminal air supply outlets for low-grade clean rooms (Class 10,000 / Class 100,000), FFU and purification equipment. Widely applied in electronics, semiconductor, pharmaceutical, hospital, food and other industries.

Notes: 1. Keep filter pleats and separators vertically placed during operation; 2. Read and strictly follow installation instructions before installation and use.
