Standard five-layer sintered filter is made by laminating five layers of stainless steel wire mesh and vacuum sintering. The finished filter cartridge features strong corrosion resistance, good permeability, high mechanical strength, easy cleaning and backwashing, accurate filtration precision, hygienic filter material and firm mesh structure without shedding.

Main connection modes: standard connectors (222, 220, 226), quick connector, threaded connection, flange connection, pull rod connection and customized interfaces. Widely applied in filtration of polyester, water treatment, oil products, pharmacy, food & beverage, chemical industry, chemical fiber as well as high-temperature air and other media.

Structure & Characteristics:

1. Composed of protective layer, precision control layer, dispersion layer and multiple reinforcing layers;

2. High strength: possesses excellent mechanical strength and pressure resistance after sintering;

3. High precision: achieves uniform surface filtration performance for particle size from 2μm to 200μm;

4. Heat resistance: suitable for continuous operation within -200℃ to 650℃;

5. Easy maintenance: surface filtration structure enables excellent backflush effect and simple cleaning.

Application Range

1. Diffusion and cooling materials in high temperature environment;

2. Gas distribution and fluidized bed orifice plate materials;

3. High-precision and high-reliability high-temperature filter elements;

4. High pressure backwashing oil filters.

Standard Specifications:

1. Standard Material: SUS316L;

2. Standard Size: 1200*1000*1.7mm;

3. Filtration Rating: 2-300μm.
