Frame: Galvanized steel frame / Aluminum alloy frame

Filter Media: Ultra-fine glass fiber

Separator: Aluminum foil separator or paper separator

Sealant: Polyurethane

Gasket: Integral injection-molded seamless polyurethane gasket

Rated air flow scanning filtration efficiency (EN1822):

H10: ≥95% @ MPPS (≥99% @ 0.3μm)

H11: ≥95% @ MPPS (≥99% @ 0.3μm)

H13: ≥99.95% @ MPPS (≥99.99% @ 0.3μm)

H14: ≥99.995% @ MPPS (≥99.999% @ 0.3μm)

Each unit is inspected one by one via laser particle counting scanning before delivery.

Max continuous operating temperature: ≤70℃

Humidity resistance: ≤100%RH

Recommended maximum final resistance: ≤600Pa

☆ Metal protective mesh is available on request

Application: Widely used for terminal filtration in high-cleanliness civil and industrial environments such as electronics, semiconductors, precision machinery, pharmaceuticals, hospitals and food processing industries.

Notes: 1. Keep filter pleats and separators vertically arranged during operation; 2. Read and strictly follow installation instructions before mounting and use.
