Both inner and outer filtration surfaces are specially singed, which effectively prevents fiber shedding contaminating filtrate and avoids excessive pore blockage caused by traditional rolling process that shortens service life. All raw materials are natural white without bleaching or dyeing, fully complying with environmental standards.

With 3D filter layer structure of needled felt, solid and colloidal particles are trapped inside and deep into the filter bag via depth filtration principle, achieving high particle retention efficiency. Uniform thickness, stable open porosity and excellent mechanical strength ensure steady filtration performance and longer service life.

The bottom, side walls and collar are fully thermally welded, eliminating bypass leakage and fiber shedding issues existing in traditional sewn filter bags. Seamless filter bags are manufactured by digital multi-point synchronous welding equipment for firm and uniform welding, ensuring consistent material quality without auxiliary material interference, ideal for high-standard industrial applications.

1. Large dirt holding capacity, high flow rate and excellent pressure resistance.

2. Easy operation, outstanding corrosion and temperature resistance.

3. High retention rate, cost-effective and wide application range.

4. Acid & alkali resistant, max working temperature up to 150℃. Non-woven fabric material, filtration accuracy: 0.5~600μm.

Filter Bag Material: Polypropylene / Polyester

Collar Material: Stainless Steel / PP
